Plastic blowing moulding machine

The 5L single-station automatic Plastic Bottle blowing machine is a single station machine, and suitable for producing high quality container with medium output. It specializes in the manufacture of PE\PP\PVC\TPU\PETA containers of up to 5L, with from one to six fold diehead, for use in the packaging of petroleum, cosmetics, chemicals, pharmaceuticals,food, toys and auto-parts. The clamping system is a high-precision single-station linear guide, extrusion system using a hard gear reducer and inverter imported from Japan.The die head system adopts central-incoming extrusion die made of special steel, imported hydraulic valve and seal parts with proportional control valve. The control system consists of PLC and Human-machine interface imported from Japan, an automatic temperature control module and imported electrical parts The Machine Can Produce all kinds of PE Container, such as PE Bottles, PE Barrels, PE Kettles etc. Setting: Clamping---------Single station+Hight-precision guide+large arm cylinder axle Extrusion system--Hard gear surface reducer+Japan inverter Die system--------Central-incoming extrusion die with special steel Hydraulic system--Japan hydraulic valve seal and proportional control Control system----Japan PLC+Imported HMI+PLC automatic Specification DHS-2LDHS-5LDHS-12LDHS-16LMaterialPEPPPEPPPEPPPEPPMax.container capacityL251216Number of dieset1234123412341234Machine Dimensionm2.5×1.6×2.42.9×1.85×2.654.2×2.95×34.8×3.2×3.1Total weightton4578Accumulator headDHS-2LDHS-5LDHS-12LDHS-16LNumber of die heatingzone3334Power of die heatingKW4.25.86-76-7Max die-pin diametermm6080140140Center distance of twin-diemm130160240260Center distance of tri-diemm85110160180Center distance of four-diemm6585120130Clamping UnitDHS-2LDHS-5LDHS-12LDHS-16LClamping forceKN3870110155platen opening strokemm158-410209-510209-620219-600platen sizemm290×320350×380460×500500×490Max mould sizemm320×320400×380560×500600×500Mould thicknessmm160-240210-300220-380210-380
