Blow moulding equipment

DHB-82PC Blow moulding equipment Is Specially for 3 gallons and 5 gallons water barrel and lamp cover with PC Material. Setting: Clamping----------Double station+Hight-precision guide+large arm cylinder axle Extrusion system--Hard gear surface reducer+Japan inverter Die system--------Central-incoming extrusion die with special steel Hydraulic system--Japan hydraulic valve seal and proportional control Control system----Japan PLC+Imported HMI+PLC automatic Specification DHB-82PC Material PC Max.container capacity L 25 Number of die set 1 Output pcs/hr 500 Machine Dimension m 6.5×2.4×4.7 Total weight ton 12 Accumulator head DHB-82PC Number of die heating zone 4 Power of die heating KW 8 Max die-pin diameter mm 150 Accumulator capacity L 1.8 General dimension m 1.2×0.5×0.42 Clamping Unit DHB-82PC Clamping force KN 220 platen opening stroke mm 330-780 platen size mm 740×630 Max mould size mm 550×660 Mould thickness mm 350-420 Extruder Unit DHB-82PC Screw diameter mm 82 Screw L/D ratio L/D 38:1 Extruding Volume Kg/hr 150 Number of heating zone zone 8 Extruder heating power KW 20 Extruder driving power KW 34 Power DHB-82PC Oil pump drive power KW 45 Fan power for screw KW 0.9 Total power KW 90 Air pressure Mpa 1.2 Air consumption m3/min 1.0 Average energy consumption KW 42
